Blister Machine | BS-300 For Solid Products

Blister Machine BS 300 is known for its compact design and sophisticated concept, our BS-300 blister packaging machine is able to flexibly meet the requirements of the pharmaceutical industry in the areas of thermoforming and cold forming, all while taking up minimal space. Contact us for blister machine supplier in India.



blister machine bs 300



  • The BS-300 blister machine is suitable for smaller production quantities and fast format changeovers. The focus of the BS-series is packing of solida products.
  • Compact design meets sophisticated concept.
  • High adaptability for the pharmaceutical industry – while taking up minimal space.

The BS-300 can achieve a maximum output of 300 blisters per minute.

Options

– Depending on the specific application the machine can be equipped with any combination of the following options:Thermo- / Coldforming
– Automatic feeding systems
– Blister inspection systems
– OPC transfer
– Active Directory
– Pin hole detection
– MES / ERP connection
– Printmark control
– Perforation
– Coding / Embossing
– Printing of lidding material
– In-Process-Control

Benefits

– GMP-compliant pharmaceutical design
– For packaging of all common solida products
– Economical even for small production batches
– Quick & easy format changeovers
– State of the art technology
– Suitable for all common form- and lidding foils including recyclable PP-foils
– High flexibility
– Intuitive operation
– Fast cleaning process
– Simple maintenance options
– Optimal accessibility
– Wide range of configurations
– Comprehensive qualification documentation

Applications of Blister Solida
Tablets
Oblongs
Capsules

Technical Info

Output [blisters/min]:

max. 300

Sealing principle:

rotary sealing, platen sealing

Reel diameter [mm]:

forming material max. 500, lidding material max. 300

Processable forming material:

laminated alu foils, PVC, PVDC, Aclar, PP and others on request

Processable lid materials:

hard alu, soft alu, paper / alu, alu with defi ned hardness and others on request

For more information Contact Us
